Aviom D400D A-Net Distributor, with Dante interface

The Aviom D400-Dante brings Aviom personal monitoring into a Dante-based audio system without making the setup more complicated than it needs to be. Instead of a standard A-Net input, this version connects directly to a Dante network and converts selected Dante audio channels into Aviom’s A-Net format for Personal Mixers.

Using Dante Controller, up to 32 channels from a 44.1 or 48 kHz Dante network can be routed to the Aviom system. From there, the D400-Dante distributes audio and DC power to up to eight Aviom Personal Mixers over Cat-5e cable, making it a practical solution for digital consoles, installed systems, houses of worship, theatres, schools and live rigs already built around Dante.

Like the standard D400, it also includes an unpowered A-Net output for adding more distributors in larger systems, plus Stereo Link DIP switches for setting up stereo channel pairs from the front panel. Dante Primary and Secondary ports are provided for network connection, and the unit supports static IP and AES67.

A neat, cost-effective bridge between Dante and Aviom, the D400-Dante is ideal when you want to keep the musicians on familiar Aviom mixers while modernising the source side of the system.

Main features

* Dante-to-A-Net distributor for Aviom personal monitoring systems
* Receives up to 32 channels from a Dante network
* Supports 44.1 kHz and 48 kHz Dante operation
* Dante Primary and Secondary RJ45 ports
* 8 powered A-Net outputs for Personal Mixers
* Additional unpowered Pro16e A-Net output for system expansion
* Provides 24V DC power to connected mixers over Cat-5e cable
* Compatible with Aviom A640, A360, A320 and A-16II Personal Mixers
* Channel routing managed in Dante Controller
* Stereo Link DIP switches for assigning stereo channels
* Supports static IP
* AES67 support
* Power, Network Sync and Dante status LEDs
* Internal power supply with IEC connector
* 2U rackmount format
