Rupert Neve Portico 5015 Preamp Compressor

The Portico 5015 H combines exceptional sound quality with precise control, offering a robust and versatile solution for tracking, mixing, and mastering applications. Whether you're capturing the subtle dynamics of a vocal performance or adding character to an instrument, the 5015 H delivers the signature Rupert Neve tone with modern functionality.

Key Features and Specifications
Microphone Preamp
Transformer-Like Amplifier (T.L.A.) Design: The balanced (but not floating) input employs a T.L.A. configuration with a toroidal Common Mode Rejection Low Pass Filter to reject frequencies above 150 kHz.
72 dB of Gain: Provides ample headroom and clean signal amplification.
Silk Circuit: Adds vintage-style warmth and presence reminiscent of classic Rupert Neve designs.
Selectable Functions:
Phase Invert: Reverses the phase of the incoming signal by 180°.
Mute: Silences the output signal after metering.
48V Phantom Power: Supplies condenser microphones with power.
Swept High-Pass Filter: Adjustable from 20 Hz to 250 Hz to attenuate unwanted low frequencies.
Compressor-Limiter
Flexible Control:
Threshold: Adjustable from -30 dBu to +20 dBu.
Ratio: Fully variable from 1:1 to LIMIT (40:1).
Attack Time: Adjustable from 20 ms to 75 ms.
Release Time: Adjustable from 100 ms to 2.5 seconds.
Makeup Gain: Ensures optimal output levels after compression.
Two Selectable VCA Modes: Tailor compression response to any source material.
Routing Options
The microphone preamp output can be routed directly to the compressor section for seamless integration.

Additional Features
Level Metering: Displays signal levels from -30 dBu to +22 dBu relative to the output.
Horizontal Faceplate: Ideal for rack installations and horizontal setups.
