JoeCo Blackbox BRR1-A Recorder. Adat-version & 24-ch Analog I/O (DB25)

An ADAT version of the famous BlackBox recorder.
SKU: K_2185
€1,068.00 incl. VAT contact_support
In stock
Select quantity:
add to cart
Shipping & VAT
format_quote The 24 channel BBR1A multi-track ADAT recorder brings the benefits of multi-track audio capture with the BLACKBOX Recorder to digital desks and D-A converters equipped with Lightpipe (TOSlink) I/O.

Three 8-channel Lightpipe inputs can be connected from the mixer while three Lightpipe outputs can return the signals back to the mixer. All other BLACKBOX multi-track recorder features remain unchanged, and the full analogue I/O capability of the standard BBR1 is still available for situations where the Lightpipe interface is not suitable.

JoeCo BLACKBOX BRR-A recorder is designed and built to the highest standards with rugged construction and a suite of unique features. It is the trusted choice of professionals all across the audio industry.

Lightpipe i/o via 3 x TOSLINK inputs and 3 x TOSLINK outputs (24 channels @ 48k, 12 channels @ 96k). Word clock input on BNC. Unbalanced analogue as BBR1U (cable looms not supplied)
format_quote US parcels are shipped fully insured with DHLExpress and they usually arrive within 2-3 working days from pickup day zero.

EU parcels arrive within 4-6 working days and are shipped with DPD or ACE Logistics.

You are also most welcome to pick up your order from Retrosonic Pro Audio showroom, studio and warehouse in Tallinn, Estonia.

We ship worldwide! Contact us for a personal shipping quote or if you have any questions.

VAT (Value Added Tax) is deducted if you have a company with a valid EU VAT number or if you're based outside of EU. Non-EU buyer pays all and any import duty and tax as regulated by your local customs.
Technical Specifications:

Sample rates: 44.1kHz, 48kHz, 88.2kHz, 96kHz.
Bit depths: 16 / 24bit
Disk interface: USB2 – easy to obtain
Disk format: FAT32 – compatible with both Mac and PC
File type: Standard mono Broadcast WAV files
Monitoring: 1 x 1/4” TRS jack socket, headphone mix / solo
Physical: 19” rack mounted 1U (425x44x150m). Weight 2.1kg
Power: (9V-16V dc (<30W). 2.1mm dc inlet. PSU supplied
Audio i/o: Analogue inputs / outputs
Levels: -10dBu / +4dBu switchable
Max input / output level: +22dBu = 0dBFS
A-D / D-A conversion: 24bit, 96kHz 106dB S/N, 96dB THD+N
(typical A-weighted)
