IGS Audio 576 Blue Stripe Rev A, FET Compressor

The FET-type solution was first used for its application in the legendary UREI 1176 compressor from the 70s. The most important feature inspired by revision A is the input transformer used and pure class A output stage. The compressor is equipped with a relay bypass, 2:1 Ratio and Slam Mode accessible on the front panel.

The 576 BS’s major selling point is its ultra-fast attack time — 20 µS. The 576 BS Ratio buttons allow four different modes of operation: 2:1 Ratio (soft compression); 4:1 ratio (moderate compression); 8:1 ratio (severe compression); 12:1 ratio (mild limiting); 20:1 ratio (hard limiting); S – SLAM, All Buttons In trick mode.

DEVICE TYPE
Fet Compressor: Yes
BASIC FEATURES
Stereo Link: Yes (linkable in PSU)
INPUT & OUTPUT
Input Impedance (balanced): 2.4k, Carnhill transformer
Output Impedance (balanced): 600 Ohm, Carnhill transformer
Audio transformers: Yes, Carnhill on input and output
LEVELS
Operating Level: +4 dBu
Max input level: +20 dBu
Max output level: +22 dBu
Noise Level: -99 dBA
Max. gain: 36 dB
Max Gain Reduction: -20 dB
TIME CONSTANTS
Ratio: 2:1, 4:1, 8:1, 12:1, 20:1, Slam (All in)
Attack: 20us - 800us
Release: 50ms - 1.1s
BANDWIDTH
Frequency response: 8 Hz to 20 kHz, +/- 0.1dB
DISTORTION (@ 20 HZ - 20 KHZ)
THD+N: 0.014%
POWER
Power consumption: 2.5W
PACKING BOX
Shipping weight: 1kg
